Roll Label Digital Die Cutting Machine Hot Stamping Rotary Die Making Machine

Ask Lasest Price
Brand Name :	Yongshi
Certification :	CE Certificate
Supply Ability :	30 Set/Sets per Month
Price :	$13,000.00 - $39,000.00/sets

Add to Cart

Product Details
Company Profile

Roll Label Digital Die Cutting Machine Hot Stamping Rotary Die Making Machine

YS-350G High speed label die cutting machine almost is researched by ourselves, it is platten press structure, computer-servo system pull paper. Unwinding-die cutting-waste discharging-rewinding(or cutting into pieces), all processes are completed by PLC system in one time.

Technical Parameters

Model	YS-350G
Max. material width	360mm
Cutting area	350*350mm
Hot stamping area	350*350mm
Max. Cutting speed	24000 times/min
Position accuracy	±0.10mm
Max. Length of meter	70m/min
Unwinding/rewinding diameter	800mm
Voltage	380v (3 phase,380v)
Total power	13kw
weight	4500kg
Size(LWH)	340016001600

Main Features

1. Pressure is very stable

2. Work very quietly,normally without noise and shake

3. Two working station can be controlled separately.

4. The cutting plate is thin and light, very easy to get out and in, it is sucked by magnetic

5. Adopt English Trio system,motion controller, intelligent servo PLC system.

6. Automatic web-guiding system

7. use wood die cutter, cheap and durable.

8. automatic lubricate system, Automatic tension control

9. It can do vertical and horizontal hot stamping

10. All are imported parts, such as electronic parts, bearing, transducer,servo motor and so on.

Roll Label Digital Die Cutting Machine Hot Stamping Rotary Die Making Machine
